Wind Turbine Tower Robot

Wind Turbine Tower Robot is an automated equipment with magnetic adsorption, vacuum wall attachment and

other mobile technologies as its core, equipped with cleaning, rust removal, spraying or detection modules.

After adaptive modification, it is extended to the field of facade maintenance in scenarios such as ships and

petrochemical storage tanks, taking into account the intelligent operation and maintenance needs in high-altitude

and high-risk environments. Its core goal is to reduce personnel safety risks through unmanned operations, while

improving surface treatment efficiency and process standardization level.

Application scenarios:

1. Petrochemical storage tanks

External wall rust removal and anti-corrosion:

Replacing manual high-altitude operations, the robot cleans an area of 80-100 square meters per day, synchronously

recovers over 95% of dust, and meets the Sa2.5 standard for cleanliness;

Inner wall inspection and maintenance:

Equipped with a thickness measuring probe for corrosion monitoring of the inner wall of the tank, with a detection

accuracy of ± 0.05mm, supporting high-temperature (≤ 150 ℃) enclosed environment operations;

High pressure water jet is used to remove residues on the inner wall, with a daily operating efficiency of 60-70 square

meters.

2. Ship maintenance:

Hull shell treatment:

Remove barnacles, marine organisms, and old coatings, and use robots in conjunction with ultra-high pressure water

jets (50-70 ㎡/h) and vacuum recovery systems to avoid secondary pollution;

Robots automate the entire process of rust removal, drying, and anti fouling paint spraying on the surface of ship hulls.

Internal maintenance of cabin:

Adapt to complex spaces such as ballast tanks and cargo holds, complete weld polishing (Ra ≤ 6.3 μ m) and anti-corrosion

 coating spraying, and reduce manual intervention by more than 90%.
